BVZAXN 12/56
00227769_0

BVZAXN 6_9_12/56

For conveying smoke gases of temperature classes F200, F300 and F400

  • For installation in the fire zone without additional cooling.
  • Low-noise operation due to low circumferential speeds and high pressure coefficients.
  • Optimised outlet guide vanes to increase the pressure coefficients.
  • Extensive adjustments to the relevant operating point and subsequent motor rating corrections can be made by steplessly adjusting the impeller blades without any need to disassemble the impeller (the impeller blades cannot be adjusted in the case of the F400 temperature class).
  • The desired operating point is optimised to achieve the best possible efficiency using a variable number of blades (6 / 9 / 12).
  • 15 sizes
  • Impeller’s nominal diameter 315 to 1,600 mm
  • Volume flow rate max. 230,000 m³/h
  • Total pressure max. 3,150 Pa
  • Casing available in all RAL colours

Application

Application

  • For installation inside and outside of the fire zone.
  • Suitable for free inlet / outlet or for pipeline installation in a horizontal and vertical style.
  • Dual smoke extract and ventilation function.
  • Based on two fans connected in series, suitable for extracting smoke from underground car parks and extract air (66% redundancy in emergency mode)

Description

Variants

  • Temperature class F200 / F300 / F400

Accessories

  • Fan diagnosis system VD
  • Volume flow rate measuring unit VME
  • Shock pulse bearing monitoring STI
  • Acoustic and thermal insulation
  • Weather protection roof for acoustic and thermal insulation
  • Round silencers TSR (inlet and outlet side)
  • Round silencers TSR with interior core (inlet and outlet side)
  • Extension duct
  • Inspection hatch
  • Self-powered shut-off damper
  • Flexible connectors
  • Matching flange
  • Equipotential bonding
  • Bellmouth
  • Cover grille (inlet and outlet side)
  • Diffuser
  • Diffuser with interior core
  • Outlet duct with cover grille
  • Mounting feet
  • Brackets (for vertical assembly)
  • Spring anti-vibration mounts
  • Terminal box
  • Local isolator loose (for outside of fire area)
  • Angular wall ring with brackets (inlet and outlet side)
  • Silicone-free type
  • Extract air and smoke extract controller
  • Surface protection powder-coated and/or
  • hot-dip galvanised in corrosion protection category C2 to C5M

Classification, standards and guidelines

  • ►For conveying smoke gases of the
  • temperature classes F200, F300 and F400
  • ►Temperature / time classification as per EN 12101 – Part 3:
  • F200 CE no.: 0761-CPD-0009, incl. declaration of performance (DoP) General building inspectorate licence no. Z-78.11-128
  • F300 CE no.: 0761-CPD-0010, or 0761-CPR-0492 for operation on a frequency inverter in the case of smoke extraction, incl. declaration of performance (DoP) General building inspectorate licence no. Z-78.11-128
  • F400 CE no.: 0761-CPD-0011, or 0761-CPR-0493 for operation on a frequency inverter in the case of smoke extraction, incl. declaration of performance (DoP) General building inspectorate licence no. Z-78.11-128

Technical information

Quick sizing

  • Quick sizing
BVZAXN 12/56 Leistungsbereich 00229560_0

t = 20 °C
ρ = 1,2 kg/m³
① Totaldruckerhöhung
② Volumenstrom

Dimensions and weight

  • Dimensions and weight
BVZAXN 12/56
00229145_0
00229145_0
00229139_0
00229151_0
00229157_0
00229163_0

Principal dimensions①Ø clear widthØkØDzxdHaa₁Cbb₁b₂③ b × l

① Ø clear width Øk ØD zxd H a a₁ C b b₁ b₂ ③ b × l

315

320

356

386

8 x 9.5

240

328

302

35

356

68

80

12 x 20

355

359

395

425

8 x 9.5

270

356

330

35

398

88

80

12 x 20

400

401

438

468

12 x 9.5

300

406

379

37

438

104

80

12 x 20

450

450

487

517

12 x 9.5

335

430

400

37

487

124

80

12 x 20

500

504

541

571

12 x 9.5

375

480

453

37

541

151

80

12 x 20

560

565

605

643

16 x 11.5

420

519

483

45

605

183

80

12 x 20

630

634

674

712

16 x 11.5

470

607

575

45

674

203

100

12 x 20

710

711

751

789

16 x 11.5

525

645

613

45

721

210

110

12 x 20

800

794

837

875

24 x 11.5

585

735

703

45

872

285

110

14 x 22

900

894

934

972

24 x 11.5

655

785

753

45

860

225

160

14 x 22

100

1003

1043

1081

24 x 11.5

730

881

833

57

940

265

160

14 x 22

1120

1124

1174

1214

24 x 11.5

760

951

903

57

1184

380

160

14 x 22

1250

1261

1311

1251

24 x 11.5

855

1051

1003

57

1321

465

160

14 x 22

1400

1415

1465

1545

24 x 11.5

⊗

⊗

⊗

⊗

1475

520

165

14 x 22

1600

1587

1637

1717

32 x 11.5

⊗

⊗

⊗

⊗

1649

615

160

18 x 25

① Nominal size •

③ Slotted hole width × length •

⊗ Upon request


Dimensions dependent on the number of extensions①②L④②L12)y④②L22)④

① ② L ④ ② L12) y ④ ② L22) ④

315

71

600

20

80

750

12

25

80

900

29

355

80

660

25

90

825

8

30

90

990

35

400

90

752

36

112

940

54

43

112

1128

51

450

90

800

43

112

1000

34

52

112

1200

62

500

112

900

56

132

1125

81

68

132

1350

80

560

112

968

82

132

1210

64

99

132

1452

117

630

132

1144

150

-

-

-

-

-

-

-

710

132

1220

130

160

1525

112

152

160

1830

174

800

132

1400

164

180

1750

104

198

180

2100

232

900

132

1492

220

225

1865

78

264

225

2238

309

100

160

1660

274

225

2075

113

329

225

2490

383

1120

180

1800

380

280

2250

180

425

280

2700

470

1250

200

2000

450

280

2500

115

500

280

3000

550

1400

180

⊗

⊗

⊗

⊗

⊗

⊗

⊗

⊗

⊗

1600

225

⊗

⊗

⊗

⊗

⊗

⊗

⊗

⊗

⊗

²⁾ Additional empty ducts are required here, so the a + a1 dimensions change

① Nominal size •

② Max. motor size •

③ Slotted hole width × length •

④ Weight without motors (approx.) [kg] •

⊗ Upon request




detailed design
