BVAXO 9/27

For conveying smoke gases of the temperature class F400

Compact size for installation even when space is tight.

Casing available in all RAL colours
13 sizes
Impeller’s nominal Ø 315 to 1,600 mm
Volume flow rate V max. 170,000 m³/h
Total pressure increase Δpt max. 1,050 Pa

Application

Application

For installation inside and outside of the fire zone.
Suitable for free inlet / outlet or for pipeline installation in a horizontal and vertical style.
Dual smoke extract and ventilation function.

Description

Accessories

Fan diagnosis system VD
Volume flow rate measuring unit VME
Shock pulse bearing monitoring STI
Acoustic and thermal insulation
Weather protection roof for acoustic and thermal insulation
Round silencers TSR (inlet and outlet side)
Extension duct
Inspection hatch
Self-powered shut-off damper
Flexible connectors
Matching flange
Equipotential bonding
Bellmouth
Cover grille (inlet and outlet side)
Diffuser
Outlet duct with cover grille
Wall mounting plate
Louvre box
Mounting feet
Brackets (for vertical assembly)
Spring anti-vibration mounts
Local isolator loose (for assembly outside of the fire area)
Angular wall ring with brackets (inlet and outlet side)
Silicone-free type
Extract air and smoke extract controller
Surface protection powder-coated and/or
hot-dip galvanised in corrosion protection category C2 to C5M

Classification, standards and guidelines

Temperature / time classification as per EN 12101 – Part 3
F400 CE no.: 0761-CPR-0491 with declaration of performance (DoP)

Technical information

Quick sizing

BVAXO Leistungsbereich 00229512_0

t = 20 °C
ρ = 1,2 kg/m³
① Totaldruckerhöhung
② Volumenstrom

Dimensions and weight

AXO 9/27

Dimensions [mm]①②Ø clear widthØkØDzxdLMmax

①	②	Ø clear width	Øk	ØD	zxd	L	M_max
315	71-80	320	356	386	8 x 9.5	150	265
400	71-90	401	438	468	12 x 9.5	188	348
400	100	401	438	468	12 x 9.5	376	390
500	80-100	504	541	571	12 x 9.5	225	570
500	90-132	504	541	571	12 x 9.5	450	451
630	90-112	634	674	712	16 x 11.5	286	595
630	132	634	674	712	16 x 11.5	572	575
800	100-132	797	837	875	24 x 11.5	350	760
800	160	797	837	875	24 x 11.5	700	810
1000	132-180	1003	1043	1081	24 x 11.5	415	730
1000	200	1003	1043	1081	24 x 11.5	830	770
1120	132-200	1124	1174	1214	24 x 11.5	450	825
1250	250-280	1261	1311	1351	24 x 11.5	500	⊗
1400	250-315	1415	1465	1545	24 x 11.5	560	⊗
1600	250-315	1587	1637	1717	32 x 11.5	630	⊗

① Nominal size, an extension duct may be needed for different sizes in the case of vibration-dampened installation •

② Motor size B3 style •

⊗ Upon request

detailed design

HERE YOU’LL HAVE DIRECT ACCESS TO SELECT THE BVAXO 9/27 VIA THE TROX X-FANS PRODUCT CONFIGURATOR

Following features are at your disposal::

Based on your requirements of volume-flow, pressure and installation arrangement including desired accessories select the ideal fan…
Appropriate selection according to required power, sound, nominal size, price and production period
Options and accessories get assessed for plausibility
All required documents (e.g. technical specification, tender specification, certificates, drawings etc.) of specific selected fan to be downloaded or send by E-Mail

Proceed to fan design

Downloads

product information

QUICK SELECTION GUIDE

2016 7,1 MB pdf

certificates

Declaration of Conformity

EN_K2_CE-Doku_Konform_TROX-X-FANS_20241010 Declaration of Conformity 310 KB pdf
Declaration of Conformity

EN_K4_CE-Doku_Konform_TROX-X-FANS_20241010 Declaration of Conformity 260 KB pdf
Type BVAXO 9/27 FU-F400

DoP/BVAXO-9/27-FU-F400 Declaration of performance 88 KB pdf
Type BVAXO 9/27-F400

DoP/BVAXO-9/27-F400 Declaration of performance 87 KB pdf
Type BVAXO-9/27-F300

DoP/BVAXO-9/27-F300/001 Declaration and Performance 87 KB pdf
Type BVAXO-9/27-FU-F300

DoP/BVAXO-9/27-FU-F300/001 Declaration of performance 88 KB pdf

operation manuals

Installation and operating manual

2,7 MB pdf
