Application
Variants
Accessories
Dimensions [mm]
AX 200 E2 01 | 199 | 205±2 | 225±1 | 129±3 | 96±3 | 180±1.5 | 204 | 201±1 | 9 | ||||
AX 250 E2 01 | 297±2 | 259±2 | 278±1 | 76±1 | 125 | 40±1 | 40±1 | 88±1 | 100 | 220 | 254±2 | 250±1 | 9 |
AX 250 E2 06 | 259±2 | 215±1 | 30±1 | 40±1 | 59±1 | 90 | 220 | 254±1 | 250±1 | 9 | |||
AX 280 E2 02 | 322±2 | 290±2 | 308±1 | 78±1 | 145 | 40±1 | 40±1 | 91±1 | 120 | 239 | 285±2 | 281±1 | 9 |
AX 315 E2 01 | 349±2 | 324±2 | 351±1 | 82±1 | 185 | 40±1 | 40±1 | 94±1 | 160 | 260 | 319±2 | 315±1 | 9 |
AX 315 E2 03 | 337±2 | 319±2 | 308±1 | 74±1 | 150 | 35±3 | 35±3 | 89±1 | 120 | 239±1 | 315±1 | 9 | |
AX 355 E2 01 | 389±2 | 363±2 | 396±1 | 97±1 | 200 | 40±1 | 40±1 | 110±1 | 175 | 300 | 358 | 354±1 | 9 |
AX 355 E4 01 | 389±2 | 363±2 | 396±1 | 97±1 | 200 | 40±1 | 40±1 | 110±1 | 175 | 300 | 358±2 | 354±1 | 9 |
AX 400 E4 01 | 307±2 | 432±2 | 416±3 | 55±1 | 250 | 40±1 | 72±1 | 70±1 | 220 | 275 | 407±2 | 403±1 | 9 |
AX 450 E4 01 | 357±2 | 467±2 | 467±3 | 85±1 | 280 | 70±1 | 72±1 | 100±1 | 250 | 310 | 457±2 | 453±1 | 9 |
AX 500 E4 01 | 398±2 | 512±2 | 516±3 | 88±1 | 290 | 70±1 | 72±1 | 108±1 | 250 | 360 | 507±2 | 504±1 | 9 |
AX 560 E4 01 | 468±2 | 573±2 | 582±3 | 115±1 | 290 | 70±1 | 72±1 | 135±1 | 250 | 440 | 568±2 | 564±1 | 9 |
AX 630 E4 01 | 538±2 | 643±2 | 654±3 | 156±1 | 340 | 70±1 | 72±1 | 181±1 | 290 | 490 | 638±2 | 634±1 | 9 |
① Nominal size; an extension duct may be needed for different sizes in the case of vibration-dampened installation
