BVW-A, dimensions [mm]①AA1BCDEFNØ GHvWab
315 | 295 | 252 | 632 | 415 | 316 | 300 | 315 | 588 | 400 | 375 | 440 | 225 | 252 | 632 |
355 | 295 | 252 | 712 | 455 | 356 | 300 | 260 | 668 | 400 | 375 | 440 | 250 | 252 | 712 |
400 | 325 | 282 | 802 | 500 | 401 | 330 | 315 | 742 | 400 | 375 | 440 | 300 | 282 | 802 |
500 | 401 | 357 | 1002 | 600 | 501 | 400 | 410 | 932 | 500 | 450 | 540 | 375 | 357 | 1002 |
630 | 516 | 452 | 1252 | 725 | 626 | 500 | 3951)/600 | 1182 | 5001)/8002) | 4251/6802)) | 6101)/7602) | 475 | 452 | 1252 |
710 | 566 | 502 | 1402 | 800 | 701 | 560 | 3951)/6002) | 1332 | 5001)/8002) | 4251/6802) | 6101)/7602) | 525 | 502 | 1402 |
1) Up to motor size 132
2) As of motor size 160
① Nominal size
BVW-R, dimensions [mm] ①A BCDEFNØ GHvWab
315 | 295 | 632 | 415 | 316 | 300 | 315 | 588 | 400 | 375 | 440 | 225 | 252 | 632 |
355 | 295 | 712 | 455 | 356 | 300 | 260 | 668 | 400 | 375 | 440 | 250 | 252 | 712 |
400 | 325 | 802 | 500 | 401 | 330 | 315 | 742 | 400 | 375 | 440 | 300 | 282 | 802 |
500 | 401 | 1002 | 600 | 501 | 400 | 410 | 932 | 500 | 450 | 540 | 375 | 357 | 1002 |
630 | 516 | 1252 | 725 | 626 | 500 | 3951)/600 | 1182 | 5001)/8002) | 4251)/6802) | 6101)/7602) | 475 | 452 | 1252 |
710 | 566 | 1402 | 800 | 701 | 560 | 3951)/6002) | 1332 | 5001)/8002) | 4251)/6802) | 6101)/7602) | 525 | 502 | 1402 |
1) Up to motor size 132
2) As of motor size 160
① Nominal size
BVW-R with inlet box, dimensions [mm] ①A A1BCDEFNØ GHvwab
315 | 295 | 252 | 632 | 415 | 316 | 300 | 315 | 588 | 400 | 375 | 440 | 225 | 252 | 632 |
355 | 295 | 252 | 712 | 455 | 356 | 300 | 260 | 668 | 400 | 375 | 440 | 250 | 252 | 712 |
400 | 325 | 282 | 802 | 500 | 401 | 330 | 315 | 742 | 400 | 375 | 440 | 300 | 282 | 802 |
500 | 401 | 357 | 1002 | 600 | 501 | 400 | 410 | 932 | 500 | 450 | 540 | 375 | 357 | 1002 |
630 | 516 | 452 | 1252 | 725 | 626 | 500 | 3951)/600 | 1182 | 5001)/8002) | 4251)/6802) | 6101)/7602) | 475 | 452 | 1252 |
710 | 566 | 502 | 1402 | 800 | 701 | 560 | 3951)/6002) | 1332 | 5001)/8002) | 4251)/6802) | 6101)/7602) | 525 | 502 | 1402 |
1) Up to motor size 132
2) As of motor size 160
① Nominal size
