ERV

ERV 23/1.0

Centrifugal fans for industrial drying systems and other applications

Bellmouth calibrated as a measuring element for volume flow rate measurements. The characteristic curves have a steep, stable progression with a wide design range and high efficiency progression. On average, the total acoustic power level of the centrifugal plug-in fans is 5 dB lower than the value of the dual-inlet casing fans with comparable flow cross-sections

19 sizes
Impeller’s nominal Ø 200 to 1,600 mm
Volume flow rate V max. 140,000 m3/h
Stat. differential pressure ps max. 3,150 Pa
Peak efficiency of 76%
Due to a high delivery coefficient, the fan can be used in a highly efficient manner across a large volume flow rate bandwidth
Impeller also suitable for installation in dryers up to a conveying temperature of +250°C
In connection with installation frame (motor outside of flow)

Application

Application

Ventilation fan for installation in VAC units and/or air-conditioning chambers.
Free inlet.
Can be installed horizontally or vertically

Description

Variants

Horizontal installation: ERV 23/1.0 and 23/1.2-FU-H
Vertical installation: ERV 23/1.0 and 23/1.2 FL-VA/VB

Accessories

Volume flow rate measuring unit VME
Flexible connectors (inlet side)
Matching flange (inlet side)
Cover grille (inlet side)
Spring anti-vibration mounts
Rubber anti-vibration mounts
Frequency inverter

Technical information

Dimensions and weight

BVERV / ERV

Dimensions [mm]

①	Ø A	H	C	Ø clear width	approx. E	F	G	b	approx. J	K	L	Øk	② z x Ød
200	255	225	290	205	520	259	141	180	353	240	400	235	6	7
224	279	225	290	228	596	259	157	180	365	240	400	259	6	7
250	306	250	290	256	617	258	179	180	403	240	420	286	6	7
280	348	250	290	288	639	260	202	180	426	240	420	322	8	10
315	386	285	350	322	710	310	220	180	478	285	500	356	8	10
355	425	320	350	361	733	310	249	180	533	285	500	395	8	10
400	468	360	435	404	860	410	270	180	594	385	675	438	12	10
450	517	400	435	453	895	410	308	180	650	385	675	487	12	10
500	571	450	435	507	940	415	345	180	736	385	705	541	12	10
560	643	530	480	569	998	430	389	180	852	405	730	605	16	12
630	712	570	480	638	1046	430	436	180	926	405	730	674	16	12
710	814	640	480	714	1186	510	496	180	1047	475	900	775	16	14
800	904	715	600	804	1240	510	550	180	1167	475	1000	861	24	14
900	1004	800	650	904	1478	680	618	180	1302	645	1150	958	24	14
1000	1105	900	650	1005	1545	680	685	180	1453	645	1115	1067	24	14
1120	1125	1000	780	1005	1679	740	734	205	1553	710	1350	1067	27	14
1250	1245	1125	780	1125	1788	745	838	205	1755	710	1450	1200	32	18
1400	1385	1260	880	1255	2040	875	960	205	1948	815	1775	1337	32	18
1600	⊗	⊗	⊗	⊗	⊗	⊗	⊗	⊗	⊗	⊗	⊗	⊗	⊗	⊗

① Nominal size; an extension duct may be needed for different sizes in the case of vibration-dampened installation •

② Number of holes z x Ød •

⊗ Upon request

detailed design

HERE YOU’LL HAVE DIRECT ACCESS TO SELECT THE ERV VIA THE TROX X-FANS PRODUCT CONFIGURATOR

Following features are at your disposal::

Based on your requirements of volume-flow, pressure and installation arrangement including desired accessories select the ideal fan…
Appropriate selection according to required power, sound, nominal size, price and production period
Options and accessories get assessed for plausibility
All required documents (e.g. technical specification, tender specification, certificates, drawings etc.) of specific selected fan to be downloaded or send by E-Mail

Proceed to fan design

Downloads

product information

QUICK SELECTION GUIDE

2016 7,1 MB pdf
