For ventilation and smoke extraction

  • Ceiling suspension
  • Compact, space-saving, flat style


Axial-type jet fans:

  • Max. thrust up to 73 N,
  • With or without outlet guide vanes (coordinated to the application),
  • Unidirectional as series: GAXO-C or GAXN
  • Reversible as series: BVGAXR / BVGAXR-C
  • Nominal sizes: 315, 400
  • Impeller made of cast aluminium or plastic, directly on the motor shaft
  • Motor arranged in the flow rate,
  • Terminal box assembled outside on the casing.
  • Sound attenuator on the inlet and outlet side
  • Edged, oval design
  • Cover grille on the inlet and outlet side,
  • Baffle plate on the outlet side


Centrifugal-type jet fans upon request:

  • Max. thrust up to 97 N,
  • Nominal sizes 50 / 75 / 100
  • Unidirectional

Application

Application

  • The TROX TLT jet fan system satisfies the requirements placed on a modern and highly effective ventilation system in underground car parks and, with appropriate project planning, can be used in line with all European statutory regulations. In addition to the cost savings, more flexible installation and simpler assembly, it offers far better effectiveness in terms of air distribution and mixing. This results in direct benefits for clients, designers, HVAC contractors, system owners and users.
  • Flat style

Description

Variants

Axial-type jet fans:

  • Unidirectional as series: GAXO-C or GAXN
  • Reversible as series: BVGAXR / BVGAXR-C


Centrifugal-type jet fans:

  • Unidirectional

Accessories

  • Possible in all RAL colours
  • Corrosion protection category C3 to C4M
  • Fan diagnosis system VD
  • Shock pulse bearing monitoring STI
  • Underground car park controller
  • CO alarm system
  • Local isolator attached (terminal box not required)

Technical information

Dimensions and weight

  • Dimensions and weight
GAXO-C
00238847_0


00238847_0
00238841_0
00238859_0
00238853_0
00238871_0
00238865_0

GAXO-C, dimensions [mm]

① L1 L2 L3 Ø clear width B B1 B2 H H1 Ø d ②

315

2111

2005

500

320

596

560

620

340

345

12

95

400

2153

2005

500

401

706

560

620

430

430

12

100

① Nominal size • ② Weight (approx.) [kg]


GAXN, dimensions [mm]

① L1 L2 L3 Ø clear width B B1 B2 H H1 Ø d ②

315

2710

2610

500

320

520

560

620

340

345

12

95

400

2774

2648

500

401

630

560

620

430

435

12

100

① Nominal size • ② Weight (approx.) [kg]


GAXR-C, dimensions [mm]

① L1 L2 L3 Ø clear width B B1 B2 H H1 Ø d c ②

315

2217

2005

500

320

569

560

620

340

345

12

106

95

400

2288

2005

500

401

706

560

620

430

435

12

142

100

① Nominal size • ② Weight (approx.) [kg]




detailed design

HERE YOU’LL HAVE DIRECT ACCESS TO SELECT THE GAX VIA THE TROX X-FANS PRODUCT CONFIGURATOR

Following features are at your disposal::
  • Based on your requirements of volume-flow, pressure and installation arrangement including desired accessories select the ideal fan…
  • Appropriate selection according to required power, sound, nominal size, price and production period
  • Options and accessories get assessed for plausibility
  • All required documents (e.g. technical specification, tender specification, certificates, drawings etc.) of specific selected fan to be downloaded or send by E-Mail

Proceed to fan design

Downloads

product information

  • QUICK SELECTION GUIDE

     2016 7,1 MB pdf

certificates

  • Declaration of Conformity

    GB_K2_CE-Doku_Konform_TROX-X-FANS_20220520 Declaration of Conformity 450 KB pdf

  • Declaration of Conformity 2006/42/EG

    380 KB pdf
